FPGA
High speed DSP processing in one XC4VFX20 or XC4VFX60 with embedded PowerPC RISC processor
FPGA configuration on-board storage
Off-the-shelf IP cores
FPGA firmware design services available upon request
Memory
2 x 32M x 16 DDR2 SDRAM (up to 256MB)
128Mbit flash device
PCI interface
PCI-X 64-bit 133MHz, 3.3V
PCI-X/PCI 64/32-bit 66MHz, 3.3V
PCI 64/32-bit 33MHz, 3.3V
PMC Pn4 64 I/O connected to FPGA A
Measured sustained bandwidth
64-bit 133MHz = 760Mbytes/s
64-bit 66MHz = 450Mbytes/s
32-bit 33MHz = 120Mbytes/s
Front Panel high speed communication
4x 2.5Gbps optical transceivers for sFPDP, Fibre Channel, Gigabit Ethernet and Infiniband applications.
I/O and Front Panel Interface
4x 2.5Gbps optical transceivers for sFPDP, Fibre Channel, Gigabit Ethernet and Infiniband applications
PMC connector Pn4 64 user I/Os
Software Support
FPGA reference design
API, documentation and sample source code
Software utility to program on-board Flash with FPGA configuration data
Device driver for Windows 2000/XP, Linux
Test /demonstration application
Custom FPGA firmware /application /driver development available upon request
Application examples
Real-time DSP functions (e.g. Floating Point FFT, FIR, Polyphase filterbanks, DDC, etc...)
Data Storage with over 1.2GBytes/s bandwidth to RAID or JBOD
Embedded processors
ASIC prototyping
|
